10 Most Common ID Printer Issues and Their Resolution

All ID card printers are designed to give us the best out-of-box experience and ease of use. However, there will be times when something unexpected happens and we’ll encounter some technical trouble while operating either the software or hardware of these printers. This article will help you do basic troubleshooting of the 10 most common ID card printer issues users may encounter when using their printers.

Printer Driver and Settings Issues

Software Update (Still Showing Update Pop-up Message After the Update)

• Download the newest version manually through our website and choose the appropriate one for your computer.

Enable Dual-Sided Printing on an Enduro (For Windows)

1. Go to Devices and Printers.
2. Right-click on the Magicard Enduro printer.
3. Choose Printing Preferences.
4. Change the Duplex Printing option to Both Sides.
5. Click Apply, then click Ok.

Printer Not Detected (Fargo dtc1250e)

1. Change Printer Driver setting on Bodno. Go to BOD>Printer Driver>scroll all the way to the right, change Print Class to fargo SDK under Fargo DTC1250e printer. Save and select Yes on the pop-up window then close Bodno.

1. Disable Bidirectional Support. Go to Control Panel>Hardware and Sound>Devices and Printer>right click on the Fargo DTC1250e printer>select Printer Properties>Ports. Uncheck the check box for Bidirectional Support.

1. Disable Automatically Detect Ribbon. On the same screen on the Control Panel, right click on the Fargo DTC1250e printer>select Printer Preferences>Device Option>then uncheck the check box for Automatically Detect Ribbon>click on the drop-down menu and select YMCKO Full Color Black Resin Overlay.

Unable to Print – Pronto

1. Check if the software is updated. If not, update the software to the latest version.
2. Check printer driver and firmware if updated. If not, update it to the latest version.

Print Quality – Faded Print Pronto

1. Once your printer driver is installed, go to your computer’s Devices and Printers folder, right-click on the Magicard Pronto and choose printing preferences.
2. This will bring up the Driver Settings window. Click on the Image tab, and choose Gamma 1 from the Color Correction drop-down menu. Click Apply.
3. Print a test card – if the image is still printing faded or light, click on the Printhead Power Options button.
4. The default printhead power is 50. Raise the Yellow, Magenta and Cyan power a few steps at a time. Click Apply and print a test card after each change.

Please note: too much power heats the ribbon and can break it. If the ribbon starts breaking, set the power back to 50.

Bodno Software Issues

Legacy USB License Key Not Detected (Pop up Message When Opening the Bodno Software)

These steps apply to discontinued Bodno USB license keys. Current licenses use an activation code; check any license on our license status page.

1. Disregard the pop-up message and click OK.
2. Once on the Bodno software, check on the upper left-hand side of the screen and see if the Bodno edition shows up. If not, close the software, unplug then replug the USB and open the software again.
3. If step 1 & 2 does not fix the issue, check if the software is on the latest version. If not, update it to the latest version.
4. If step 3 does not fix it. Perform a clean installation. Uninstall Bodno software. Remove all folders that contain Bodno in it. Restart the computer then reinstall the Bodno software. Note* Make sure to save the card template on their computer before uninstalling the software.
5. If step 1 to 4 does not work. Reformat the USB dongle.

MACPRINT: Your Application Passed an Invalid Page Format Object

1. Go into print then settings make sure your card size is set to cr80

Set the Printer to Print Front and Back on MacOS

1. If you were using a Mac, open the ID card design that you want to print using the Magicard Enduro3E ID card printer.
2. Click on the Print button, and choose Advanced Options in the next screen.
3. Select Printer Features from the drop-down menu and change the option under Duplex Printing to Both Sides.
4. Choose Save Current Settings as Preset option and click OK. This would save the settings as default, and allow you to print double-sided ID cards easily in the future.
5. Make sure you select card back and set it to color

Connecting a CSV Database

1. You should be able to connect any Bodno project to a CSV database, through the Silver or any higher edition.
1. On the Database Connection Wizard, you must choose the "Direct CSV TXT File Driver" entry.
2. When setting it up, you must define the correct field delimiter and indicate whether or not your file contains column headers.
3. Note that this connectivity is read-only, so you will only be allowed to link the database information to the layout elements and print it.
4. Any necessary value changes need to be applied outside of our software, directly in the database source.

Printer Hardware Issues

Breaking Ribbon on a Badgy200

1. Tape the ribbon together
2. Update your printer’s drivers and firmware to the newest versions.
3. Clean your printer. Regularly cleaning the printer will keep out dust and debris, which can damage the print head. Watch the video on how to clean your printer.
4. Make sure your ribbon cartridge is installed correctly.
5. Calibrate the ribbon sensor.
6. Try using a different ribbon.
7. Ensure that you are using the correct power supply (each printer comes with a power supply). Also make sure that the printer is not plugged into a surge protector.
8. Make sure you are not using CR79 sized cards.

These are all basic troubleshooting steps that can fix common problems you have with your printing devices. However, if you still encounter problems after following these, please contact our tech support team to get you the resolution for your concerns.
